- Place of Origin: Tianjin
- Brand Name: jianfeng
- Model Number: JF-2000
HZS concrete Zhengzhou Hydraulic Machinery Co., Ltd. "JF2000 type self-loading concrete mixers Manual" Page 1 of 9 JF2000 Double-cone tipping self-loading concrete mixers 1, uses concrete mixer capacity of 3200L, the discharge capacity of 2000L ( tamping), capable of producing low-flowing concrete, but also to adapt to the RCC production. Allow aggregate maximum diameter of 150mm. It can be used in a large amount of hydraulic engineering concrete construction sites. Mixing tube axis 2, the technical parameters Unit Index type double cone, Tilt-loading capacity L 3200 discharge capacity (tamping) L 2000 allows a maximum particle size mm 150 Mixing drum speed r / min 14.6 ° 15 elevation work Stripper agitation cylinder axis angle ° 50 cylinder air working pressure MPa ≥0.6 hardened helical gear reducer G107-Y15-4P-18-M1 motor power KW 15 × 2 motor speed r / min 1450 dimensions (L ) mm (W) mm (H) mm 371528152475
- Place of Origin: Tianjin
- Brand Name: jianfeng
- Model Number: JF-2000
