(A) the main technical parameters:
No.
project
parameter
1
Shock shock force
88KN
2
Vibration frequency
5000 times / min
3
amplitude
15mm
4
noise
95db (A)
5
Vibration time
6 seconds / times
6
Dimensions
4000 * 2300 * 2700 (mm)
7
Capacity
38KW
8
Total Weight
12 t
9
greatest pressure
10 t
10
Pallet size
1180 * 880 * 30 (mm)
11
Number of operators
12 people
12
Land area
≥5000m2
(B) for brick and yield:
Product specification L * W * H (mm)
Forming Number
Production per hour
Production cycle
Porous brick 240 * 115 * 90
24
5760
15 seconds / times
Standard bricks 240 * 115 * 53
51
12240
15 seconds / times
(Hollow brick 390 * 190 * 190
10
2400
15 seconds / times
(Iii) Features:
The models are the main features: The device is fully automatic computer control system, the original JF-QM6-15 type device, based on the increase of the frequency converter, PLC pure original imported from Japan, and refers to the Japanese technology in automatic control program the equipment to do a lot of past adjustments to the stability of the equipment program to Zhen perfect. At the same time, to ensure the stability of the equipment under the premise, through continuous improvement, equipment vibration force and vibration frequency increases, with unique hydraulic and auxiliary systems, use the device produced products greatly improved compactness and strength, make up Pastes pressure currently exists on the market is not enough, the disadvantage of the people questioned the existence of unburned quality. The device is the replacement of mold can produce various models and sizes of standard hollow block brick, reached a multi-purpose machine effect, eliminates the waste of money that you want to increase the equipment caused by the production of different products.
By making continuous improvement from the stirring device to a brick truly automatic operation, saving labor, due to the high degree of compaction to produce the products, so the use of the equipment produced by the standard brick was palletizing can greatly save manpower, and first to solve the initial plant invested large sums of money to buy a lot of pallets problem, because our equipment standard bricks only need about 50 pallets. Because the models most accessories used on domestic and even international leader in high-quality products, so the device is slightly higher in price relative to other manufacturers of similar products, but on the stability of the equipment, it is not generally similar products can be achieved . Due to good stability of the device failure rate, reduce the use of the process of maintenance and replacement parts costs, plus eliminating unnecessary maintenance time and improve productivity, increase the value, so together to see the device relative to other value for money, or similar products, mainly for large and medium-sized enterprises.
